Fire-Retardant Quick-Install Off-White PVC Wall Cladding

This wall cladding system is manufactured from rigid PVC compound with integrated fire-retardant additives. The 8 mm thickness provides structural integrity for vertical wall mounting. Each panel has a width of 20 cm and incorporates a square hole pattern along the installation edges. The off-white surface finish provides a neutral base tone suitable for various interior color schemes. The fire-retardant formulation meets interior building material requirements for flame spread reduction. Suitable for commercial and residential spaces requiring enhanced fire safety compliance.

8 mm Thickness

20 cm Width

Square Hole Pattern

B1 Fire Rating

Core Functional Advantages

Fire-retardant composition: PVC formulation with flame-suppressant additives achieving Class B1 fire rating (self-extinguishing within 5 seconds of flame removal).
Square hole fastening system: Pre-formed square apertures spaced at 150 mm intervals allow screw or nail fixation without pre-drilling, reducing installation time.
Off-white surface finish: Neutral matte coating provides consistent light reflectance of approximately 75 percent, suitable for spaces requiring uniform illumination.
Waterproof core: Closed-cell PVC structure with water absorption rate below 0.1 percent prevents moisture-related degradation.
Low smoke emission: Fire-retardant formulation limits smoke density during combustion events (Ds max less than 150).

Technical Specifications

Composition PVC with fire-retardant additives

Thickness 8 mm ±0.2 mm

Width 20 cm

Hole shape Square

Hole spacing 150 mm center to center

Surface finish Off-white, matte, smooth

Fire classification Class B1 (GB 8624-2012 / EN 13501-1)

Product Characteristics

Edge joint design: Tongue-and-groove profile on longitudinal edges for continuous surface assembly and moisture barrier continuity.

Installation method: Direct wall mounting using screws or nails through square holes; adhesive application optional.

Weight per square meter: Approximately 1.35 kg, reducing structural load requirements.

Chemical resistance: Resistant to diluted acids, alkalis, and common cleaning agents used in commercial settings.

Dimensional stability: Linear expansion coefficient of 0.065 mm per meter per degree Celsius.

Surface cleanability: Non-porous finish allows sanitation with mild detergent and water without surface degradation.

Application Scenarios

Commercial kitchens and food processing areas: Fire-retardant surface meets health code requirements while resisting grease and moisture.
Hospital corridors and patient rooms: Off-white finish provides clinical appearance with easy sanitation protocols.
Office building stairwells and escape routes: Class B1 fire rating required by building codes for evacuation paths.
Hotel guest room bathrooms: Waterproof and fire-retardant properties suit high-occupancy hospitality environments.
Educational facility corridors: Impact-resistant surface withstands daily traffic while meeting fire safety standards.
Retail store fitting rooms and back-of-house areas: Neutral color provides uniform background for branding elements.

Performance Data

Flame spread index Less than 25 (ASTM E84)

Smoke developed index Less than 50 (ASTM E84)

Flexural strength 30 MPa at 23 degrees Celsius

Water absorption Less than 0.1 percent (24h)

Density 0.58 g per cubic centimeter

Installation & Safety Considerations

01

Square hole fastening: Use pan-head self-tapping screws or galvanized finish nails. Align fasteners with square holes. Maintain 1 to 1.5 mm gap between fastener head and panel surface for thermal movement.

02

Cutting procedure: Use fine-tooth saw blade with 10 to 12 teeth per inch. Deburr cut edges with medium-grit sandpaper to ensure proper joint alignment.

03

Storage conditions: Store panels horizontally in original packaging at 10 to 35 degrees Celsius. Maximum stack height: 1.5 meters.

04

Substrate requirement: Install on flat, dry, clean surfaces. Maximum substrate irregularity: 2 mm per meter.

Common Questions & Technical Solutions

What is the fire rating certification?	Class B1 according to GB 8624-2012 standard. Test reports available upon request. Self-extinguishing properties verified by third-party laboratories.
Can panels be installed in high-humidity environments?	Yes. The closed-cell PVC structure with water absorption below 0.1 percent permits installation in bathrooms, laundry rooms, and commercial wet areas.
How to clean the off-white surface?	Use soft cloth with mild detergent and water. Avoid abrasive cleaners, bleach, or steel wool which may scratch the matte finish.
What fastener type works with square holes?	Number 6 or number 8 self-tapping screws (length 20 to 30 mm) or galvanized spiral nails. Fastener head diameter should not exceed 8 mm.
Are expansion gaps required?	Leave 3 to 5 mm expansion gap at wall corners, ceiling junctions, and fixed obstacles. Cover gaps with matching PVC trim profiles.
What is the operating temperature range?	Minus 5 degrees Celsius to 55 degrees Celsius for interior applications. Avoid placement near heat sources exceeding 70 degrees Celsius.

Material Limitations

Not suitable for exterior applications or direct UV exposure without additional coating.
Do not install within 500 mm of open flame sources (gas stoves, fireplaces) without additional shielding.
Avoid contact with chlorinated solvents, acetone, or aromatic hydrocarbons which may cause surface softening.
Panels are decorative cladding only; not rated for structural load-bearing applications.

Warranty & Compliance

Manufacturer warranty: 10 years against manufacturing defects and delamination under normal interior use.
Compliance: Meets Class B1 fire standard requirements for commercial and residential interior wall finishes.
Formaldehyde emission: Non-detectable levels per EN 717-1.
Warranty exclusions: Improper installation, mechanical damage, or exposure to extreme environmental conditions.

Technical specifications represent standard manufacturing parameters. Variations may occur within industry tolerances. Verify compliance with local building codes and fire safety regulations before installation.

Composition:	PVC
Thickness (mm):	8
Width (cm):	20
Shape of the hole:	Square
